Home/Products/Digital Volt-Amp Meter with Inbuilt CT Coil
Digital Volt-Amp Meter with Inbuilt CT Coil — front view
1 / 3 — Front view
Download datasheet (PDF) View full PDF
PANEL METER

Digital Volt-Amp Meter with Inbuilt CT Coil

COMPACT. SELF-POWERED. NO EXTERNAL CT.

A compact, self-powered dual-display meter that reads voltage and current together through an inbuilt CT coil — no external CT, no extra wiring, no extra panel space. Built for submersible pump panels and agricultural voltage monitoring.

VOLTAGE180–450VAC
CURRENT0–60A (CT coil)
ACCURACYClass 1.0
POWERSelf powered
Enquire about this product
FULL SPEC SHEET

Technical specifications.

PRODUCT NAMEDigital Volt-Amp Meter with Inbuilt CT Coil
MEASURING RANGEVoltage: 180 to 450VAC · Current: 0–60A (through CT coil)
ACCURACYClass 1.0
DISPLAY3-digit 7-segment LED (Voltage – Red, Current – Red)
SIZE OPTIONS72×72mm, 96×96mm
AUXILIARY POWERSelf powered
FREQUENCY50/60Hz
MOUNTINGPanel mounted
WHERE IT'S USED

Applications.

Submersible pump panels Agriculture voltage monitoring
ORIGINAL DOCUMENT

View the datasheet.

The full manufacturer spec sheet, embedded below — or download it directly.

CAN'T SEE THE PDF ABOVE? DOWNLOAD IT DIRECTLY →
