Digital Metering Panel (Three Phase) — front view
1 / 2 — Front view
Download datasheet (PDF) View full PDF
SURFACE MOUNTED METER

Digital Metering Panel (Three Phase)

SURFACE MOUNTED

A compact, surface-mounted volt-amp meter with RYB phase indicators, screw-type input/output terminal connectors and a durable metal front plate — built for submersible pump panels and agricultural voltage measuring.

VOLTAGE180–450VAC
CURRENT0–60AAC
MOUNTINGSurface mounted
SIZE120×120mm
Enquire about this product
FULL SPEC SHEET

Technical specifications.

PRODUCT NAMEDigital Metering Panel (Three Phase)
METER TYPEDigital Volt-Amp meter with RYB indicators
VOLTAGE RANGE180–450VAC
AMPERE RANGE0–60AAC
CONNECTION TYPEDirect connections
INDICATIONRYB LED indicators
MOUNTINGSurface mounted
SIZE120×120mm
FRONT PLATEMetal surface plate
WHERE IT'S USED

Applications.

Submersible pump parameters Agriculture voltage measuring
ORIGINAL DOCUMENT

View the datasheet.

The full manufacturer spec sheet, embedded below — or download it directly.

CAN'T SEE THE PDF ABOVE? DOWNLOAD IT DIRECTLY →
